Is there a way to pick up sensor values, such as temperature, from URA on Magnus tags?

Modified on Mon, 14 Oct at 6:03 PM

Is there a way to pick up sensor values, such as temperature, from URA on Magnus tags?

With URA you can only get the Sensor Code and the On-Chip RSSI. On-Chip RSSI is important in order to determine the validity and quality of the Sensor Code and Temperature measurements. With URA it is not possible to get the Temperature measurements. To get the Sensor Code and On-Chip RSSI with URA set employ the following settings: Under data, check Embedded Read, set MemBank to “Reserve”, fill start box with “0xC”, set length to 2. Under filters, apply Filter1, set MemBank to ”User”, fill the start box with “0xD0”, fill Filter Data with “0x1F”, set Target to “INV S0”, and set Action to 0. Proceed to fix the frequency channel to the center of the FCC band.
